Man power required.................................... ..................................... one operator with one assistant

 - Total power required: .................................................................. ........................................15.5 K.W

 - Set up t ime:............................................................... . ..................... ...................................... 15 MIN

 - Working hours per day:.................................................................. ....................................... 8 TO 16

 - Line d irection............................... ....................................... left to right while facing operator panel

 - Overall machine length required:...................................................... ...................................... 13.6M

 - Overall packing s hippment:......................................... ...................................... one 40FT container

 - Approximate machine height:............................................................. ....................................... 1.6M

 - Machine frame................................................................... ...................................... H-BEAM fram

 Type of material to be p rocessed:................. ....................................... Galvanized/Pre-painted steel

 - Thickness of coil: ............................................. .............................................................0.3-0.8 mm

 - Max. weight of coil:........................................................................ .......................................5 000kg

 - Variable line speed:...................................... ...................... 20 mtr./min.(not includes press and  cut)

- Material loading system....................................................... .................................................Manual

 - Accuracy level: ............................... ................................... PROFILE DIMENTION: +/- 0 .5 M.M.

            .......................................... ........................ ANGULAR DIMENTION: +/- 1 DEGREE

              ............................................ ........................ .BEND/TWIST/WARP: 0 .5 MM/MTR.

              ......................................... ....................... END FLAIR(AT CUT END):+/- 0 .5 M.M.

- No. of Work Station............................. ...............................................................16 s ets for profile 1

                                    ............................... ...........................18 sets for profile 2

 - Thickness of Coil.............................................................. ................................................0.3-0.8 mm

- Max. Roll shafts Dia................................................................ ................................................ 76mm

 - Max. Line Speed................................ ...............................................2 0mtr./min(Not include shear)

 - Required Motor Capacity....................................................... ..............................................7.5 K.W

 - Roller material: ....................................................... .............................  GCr1 5, double machining

- Coil width........................................ .................................................. 1 22 0/ 914 mm for above Panels

 - PLC controller :............................................................... ................................................... Siemens

- Transducer:..................................................................... ................................................... Yaskawa  - Encoder :..................................................................... .......................................................... KOYO

- Other electronic components ............................... .............................................................Schneider

- Transmission:......................................... .................................... . ..................... chain  driving system

 - Cages................................................... ........................................ . ............... use the strong steel nets

 - Levelling screws on base ....................... . .. ..................................................... with t hick metal plate
